Moulding Machine Plastic Mold Maker Prototype Injection Molding Mould Custom

Product Details

Place of Origin: Zhejiang, China

Brand Name: TK

Certification: ISO9001:2008

Payment & Shipping Terms

Minimum Order Quantity: 100 pieces

Price: $3.50/pieces 100-999 pieces

Get Best Price

Product Details

Product Description

Highlight:

Shaping Mode:	Plastic Injection Mould	Product Material:	Plastic
Product:	Vehicle Mould	Product Name:	Mold Maker Prototype Injection Molding Mould
Application:	Matte, Glossy, High Polish, Mirror Polishing, Texture, Chrome Plating	Material:	ABS/PA66/PP/PC/PMMA/PSU/PCTG/TPE/TPU/PBT
Mould Material:	P20/718/738/NAK80/S136/2738/2316	Design Software:	2D/3D/CAD/DWG//STEP/PDF/UG
Color:	Customized Colors	Size:	Customized Size
Mould Life:	250000-300000shots	Surface Treatment:	Matte, Glossy, Texture, Silk Screen, Chrome Plating, Spray Painting

Shaping Mode:	Plastic Injection Mould
Product Material:	Plastic
Product:	Vehicle Mould
Product Name:	Mold Maker Prototype Injection Molding Mould
Application:	Matte, Glossy, High Polish, Mirror Polishing, Texture, Chrome Plating
Material:	ABS/PA66/PP/PC/PMMA/PSU/PCTG/TPE/TPU/PBT
Mould Material:	P20/718/738/NAK80/S136/2738/2316
Design Software:	2D/3D/CAD/DWG//STEP/PDF/UG
Color:	Customized Colors
Size:	Customized Size
Mould Life:	250000-300000shots
Surface Treatment:	Matte, Glossy, Texture, Silk Screen, Chrome Plating, Spray Painting

Moulding Machine Plastic Mold Maker Prototype Injection Molding Mould Custom

Product Description

What is Plastic injection molding?

Injection moulding (U.S. spelling: injection molding) is a manufacturing process for producing parts by injecting molten material into a mould, or mold. Injection moulding can be performed with a host of materials mainly including metals (for which the process is called die-casting), glasses, elastomers, confections, and most commonly thermoplastic and thermosetting polymers. Material for the part is fed into a heated barrel, mixed (using a helical screw), and injected into a mould cavity, where it cools and hardens to the configuration of the cavity. After a product is designed, usually by an industrial designer or an engineer, moulds are made by a mould-maker (or toolmaker) from metal, usually either steel or aluminum, and precision-machined to form the features of the desired part. Injection moulding is widely used for manufacturing a variety of parts, from the smallest components to entire body panels of cars. Advances in 3D printing technology, using photopolymers that do not melt during the injection moulding of some lower-temperature thermoplastics, can be used for some simple injection moulds.

Material

Surface finsh

Standard Finish	Moldmaker's choice of finish. Typically SPI B-2, depending on geometry and drafts. Interior, non-cosmetic faces, are typically as-machined.
SPI Finishes	Range of Society of Plastics Industry (SPI) finishes from Grade 3 diamond / high polish to 320 stone low polish. Finishes include: SPI A-1, SPI A-2, SPI A-3, SPI B-1, SPI B-2, SPI B-3, SPI C-1, SPI C-2, SPI C-3, SPI D-1, SPI D-2, and SPI D-3
Other Textures - VDI	VDI 3400 Surface Finish (commonly known as VDI surface finish) refers to the mold texture standard set by Verein Deutscher Ingenieure (VDI), the Society of German Engineers. This is mainly processed by EDM machining, producing fine to coarse matte finishes.
Threaded Inserts	We can install most commonly used standard inserts in UNF and metric sizes.
Silk Screen	For logo
Laser Engraving	Engrave part numbers, logos, and more onto your parts.
Assembly	We can do the assembly work for you and custom package.
Product Name	plastic molding parts

Design Suggestions

Undercuts	Reduce undercuts, which will increase the complexity and cost of the tool ejection mechanisms, by adding in pass-thru coring.
Wall Thickness	Prevent wall sink and voids by maintaining an even wall thickness. Thinner walls reduce cycle time and reduce costs.
Drafts	Ensure parts are designed with a minimum draft angle of 0.5°, or up to 5°, for faces with medium textures.
Ribs/Gussets	Ribs should be 40-60% the thickness of outer walls and should still maintain draft.
Bosses	Bosses should be designed at a depth of 30% the wall thickness and with a 30% edge groove. Attach them to side walls or ribs for structural integrity.

Application of injection molding

The Top 6 Industrial Applications for Injection Molding For most industries, it only makes sense to find the lowest cost yet most durable materials to produce the products they need. As a versatile manufacturing technique, injection molding plays a crucial role in developing and creating many modern products, from consumer toys to airplane components. This article will look at the top 6 industrial applications for injection molding and how manufacturers can improve existing systems. Food and Beverage When it comes to injection molding, the food and beverage industry relies heavily on plastic materials to create product packaging and containers. Since this industry must adhere to strict sanitization and safety regulations, plastic injection molding is an obvious fit to ensure various specifications are achieved, including BPA-free, FDA-certified, non-toxic and GMA-safe regulations. From components as small as bottle caps to the trays used in TV dinners, injection molding provides a one-stop-shop for all the food and beverage industry’s packaging and container needs. Automotive Parts Many of the parts found on modern automobiles require a broad range of intricately designed features to function correctly. For this reason, many of the leaders of the automotive industry have turned to plastic injection molding to develop, plan, and manufacture the parts they need. Typical injected molded elements include bumpers, dashboards, and smaller pieces, such as cup holders and mirror housings. Medical & Pharmaceuticals As many medical products must be shatter-proof, non-porous, and perfect in shape, plastic injection molding is critical for medical and pharmaceutical production. As a high volume producer, the medical industry can benefit from injection molding’s decreased production times and affordable production materials while still achieving high-quality medical-grade products. Medical and pharmaceutical parts created with injection molding can range from pill bottles to x-ray components. Household Products With just a simple trip to your kitchen, there is a good chance that you will find an injection molded product or part. From Tupperware to building materials used in the construction, there is no denying that this industry would not be where it is today without injection molding. Like other industries, household products can be made more affordable by investing in large production runs for shipping to retail locations worldwide. Agriculture Historically, it was typical for the agriculture industry to invest in metal-made components simply because they provided a durable solution. Now, reinforced plastic options have gained favor due to new plastic material characteristics like UV-resistance, impact-resistance, humidity resistance, and much more. The ability to create durable agriculture products that stand up to the elements on a farm makes plastic injection molding an obvious fit for the agriculture industry, from feeding troughs to specialized harvesting components. Electronics Although many people see electronic components as a predominately metal piece of machinery that uses electricity to function, enhancing system longevity with corrosion-resistant plastic housings improves overall performance. As you may have guessed, manufacturing housings through the plastic injection molding processes is preferred. The computer mouse you may be using right now, to the television in your living room, likely have some components created using plastic injection molding.

Company Profile

Yuyao Taike Mold

Yuyao Taike Mold Factory is located in the Kingdom of Plastics - the city of molds, a beautiful water town in the south of the Yangtze River, the coast of the East China Sea, and the "China Light Industry Mold City" in the northern suburb of Yuyao City, Ningbo. The Shanghai-Ningbo Railway, the Nanjing-Shanghai Expressway, and the Hangzhou-Ningbo Expressway run through the industrial zone, only 70 kilometers away from Ningbo Lishe Airport, 40 kilometers away from Xiaoshan International Airport; 15 kilometers away from Hangzhou Bay Bridge, the longest bridge in the world, and only 2 kilometers away from the railway station. The traffic is very convenient .

Yuyao Taike Mold Factory is a company integrating professional mold design, manufacturing and processing as well as plastic product processing. The company has several sets of domestic advanced mold manufacturing equipment such as machining center, electric pulse, large radial arm drilling, milling machine, grinding machine, wire cutting and wire cutting. It has a complete and scientific quality management system. The integrity, strength and product quality of Yuyao Taike Mold Factory have been recognized by the industry. Welcome friends from all walks of life to visit, guide and negotiate business.

* We provide

Semi-Automatic PET Bottle Blowing Machine Bottle Making Machine Bottle Moulding Machine
PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.
